Migrate from Lookup V1 to Lookup V2

Twilio's Lookup API has helped customers build customer onboarding experiences that seamlessly improve deliverability, mitigate risk, and produce a better user experience. We're excited to expand the Lookup API capabilities with new features and expanded geographic coverage with Version 2 of the API, now in Public Beta.

For new development, we encourage you to use Lookup V2 instead of Lookup V1. V2 is an evolution of V1 with improved support for formatting, validation, line type, carrier, and caller name lookup plus new features like SIM swap and call forwarding.

With continued support for formatting and validation, line type and carrier detection, and caller name information, V2 includes the following enhancements:

🌏 Global support for line type detection, including VoIP 🎉

☎️ 12 line type response options (expanded from 3) including: fixedVoip, nonFixedVoip, landline, mobile, personal, tollFree, premium, sharedCost, uan, voicemail, pager, and unknown.

✅ Improved phone number validation error handling, with error messages including INVALID_COUNTRY_CODE, TOO_SHORT, and TOO_LONG.

🆕 New data packages like SIM swap and call forwarding detection.

This blog post will provide the technical requirements to migrate from Lookup V1 to V2.

Migration requirements for phone number Lookup V2

The new API uses a different API URL (or helper library method call) and will have additional response fields dependent on the data package you request.

API differences between Lookup V1 and V2

V2 Base URL

The new base URL (and associated helper libraries) use v2 instead of v1 so 'https://lookups.twilio.com/v1/PhoneNumbers/+15108675310' becomes 'https://lookups.twilio.com/v2/PhoneNumbers/+15108675310'.

Type becomes Fields

To request additional data, use the Fields parameter in V2. Possible values include:

line_type_intelligence (replaces carrier from V1)
caller_name
sim_swap
call_forwarding
live_activity

Request multiple Fields by comma-separating field names.

// v1 request
curl -XGET \
'https://lookups.twilio.com/v1/PhoneNumbers/+15108675310?Type=caller-name&Type=carrier' \
-u $TWILIO_ACCOUNT_SID:$TWILIO_AUTH_TOKEN

// v2 request
curl -XGET \
'https://lookups.twilio.com/v2/PhoneNumbers/+15108675310?Fields=caller_name,line_type_intelligence' \
-u $TWILIO_ACCOUNT_SID:$TWILIO_AUTH_TOKEN

New response fields

The response JSON is the same with the addition of the following fields:

V2 new response field	Description
calling_country_code	International dialing prefix of the phone number defined in the E.164 standard. Examples include '1' for the US or '57' for Colombia.
valid	Boolean that indicates if the phone number is in a valid range that can be freely assigned by a carrier to a user.
validation_errors	Contains reasons why a phone number is invalid. Possible values: TOO_SHORT, TOO_LONG, INVALID_BUT_POSSIBLE*, INVALID_COUNTRY_CODE, INVALID_LENGTH, NOT_A_NUMBER.
Other	New packages only available in V2 like 'sim_swap' and 'call_forwarding' (others may be added at a later time)

See V2 API documentation for more resource details and code samples in multiple languages.

Line Type Intelligence is the new Carrier Lookup

Lookup V2 Line Type Intelligence (LTI) is an improvement on the V1 version of carrier lookup with more line type options and global support for VoIP detection (VoIP detection was US only in V1).

LTI (v2) has 12 possible line types (e.g. mobile, nonFixedVoip) compared to carrier (v1) which only had 3 possible line types. LTI continues to return carrier information (e.g. Verizon, O2) when available.

Here is a comparison of the V1 carrier lookup vs V2 LTI lookup in JavaScript.

Carrier (V1):

client.lookups.v1.phoneNumbers('+15108675310')
  .fetch({type: ['carrier']})
  .then(phone_number => console.log(phone_number));

// response
{
  callerName: null,
  countryCode: 'US',
  phoneNumber: '+15108675310',
  nationalFormat: '(510) 867-5310',
  carrier: {
    mobile_country_code: '310',
    mobile_network_code: '800',
    name: 'T-Mobile USA, Inc.',
    type: 'mobile',
    error_code: null
  },
  addOns: null,
  url: 'https://lookups.twilio.com/v1/PhoneNumbers/+15108675310?Type=carrier'
}

Line Type Intelligence (V2):

client.lookups.v2.phoneNumbers('+15108675310')
  .fetch({fields: 'line_type_intelligence'})
  .then(phone_number => console.log(phone_number));

// response
{
  callingCountryCode: '1',
  countryCode: 'US',
  phoneNumber: '+15108675310',
  nationalFormat: '(510) 867-5310',
  valid: true,
  validationErrors: [],
  callerName: null,
  simSwap: null,
  callForwarding: null,
  liveActivity: null,
  lineTypeIntelligence: {
    mobile_network_code: '800',
    carrier_name: 'T-Mobile USA, Inc.',
    error_code: null,
    mobile_country_code: '310',
    type: 'mobile'
  },
  url: 'https://lookups.twilio.com/v2/PhoneNumbers/+15108675310'
}

See V2 code samples in more languages in the documentation.

Caller Name Lookup: V1 to V2

The request is very similar in V2 but for API consistency, the V2 caller_name parameter uses snake case.

V1:

client.lookups.v1
 .phoneNumbers("+12127363100")
 .fetch({ type: ["caller-name"] })
 .then((phone_number) => console.log(phone_number.callerName));

V2:

client.lookups.v2
 .phoneNumbers("+12127363100")
 .fetch({ fields: "caller_name" })
 .then((phone_number) => console.log(phone_number));

// response
{
  callingCountryCode: '1',
  countryCode: 'US',
  phoneNumber: '+12127363100',
  nationalFormat: '(212) 736-3100',
  valid: true,
  validationErrors: [],
  callerName: {
    caller_name: 'EMPIRE STATE BL',
    caller_type: 'CONSUMER',
    error_code: null
  },
  simSwap: null,
  callForwarding: null,
  liveActivity: null,
  lineTypeIntelligence: null,
  url: 'https://lookups.twilio.com/v2/PhoneNumbers/+12127363100'
}

Error handling

In V1, an invalid phone number like +123 would return an HTTP 404 response.

In V2, an invalid phone number like +123 will return an HTTP 200 with valid=false and validation errors like TOO_SHORT. This is useful to propagate error messages back to an end user for potential typos or gain insight into the type of invalid numbers in your database.

Possible validation errors include: TOO_SHORT, TOO_LONG, INVALID_BUT_POSSIBLE*, INVALID_COUNTRY_CODE, INVALID_LENGTH, NOT_A_NUMBER.

This change applies to all requests regardless of requested fields.

*INVALID_BUT_POSSIBLE means the phone number has the correct length, but is invalid based on its prefix. Since the application of phone numbering plan updates to Lookup can be delayed, handling this error can provide you a way to offer a more lenient check on number validity.

Best practices

Instead of calling Lookup before every time you send a one-time passcode, trigger an API request when you collect a new phone number like at sign up or during a phone number change. This will help you prevent typos and potential fraud.

Learn more about best practices for phone number validation during new user registration.

Use Lookup to audit your database

Many customers perform periodic (e.g. quarterly or annually) database clean up. You can use Lookup to determine if numbers are still valid or still the expected line type. This will help prevent sending messages to landline numbers.

FAQ

What is the difference between Carrier Lookup and Line Type Intelligence?

V1 carrier lookup returns 3 line types: mobile, landline, and voip. VoIP detection only works for US numbers with carrier lookup.

V2 Line Type Intelligence returns 12 different line types and the information is available globally. Available line types for LTI include:

Type	Description
landline	The phone number is a landline number; generally not capable of receiving SMS messages.
mobile	The phone number is a mobile number; generally capable of receiving SMS messages.
fixedVoip	A virtual phone number associated with a physical device (e.g., Comcast or Vonage).
nonFixedVoip	A virtual phone number that can be obtained on the internet without the need for a physical device (e.g., Google Voice or Enflick).
personal	A phone number designated for personal use.
tollFree	A toll-free phone number, which is one where calls are free for the calling party.
premium	A premium rate phone number, which typically charges higher than normal rates for special services.
sharedCost	A shared cost phone number, which is one where the charge is partially paid by the calling party and charges higher than normal rates.
uan	A universal access number, which is a national number which can route incoming calls to different destinations.
voicemail	A phone number associated with a voicemail service.
pager	A phone number associated with a pager device.
unknown	A valid phone number, but the line type could not be determined.
