Workflow Automation with Python and Flask

One of the more abstract concepts you'll handle when building your business is what the workflow will look like.

At its core, setting up a standardized workflow is about enabling your service providers (agents, hosts, customer service reps, administrators, and the rest of the gang) to better serve your customers.

To illustrate a very real-world example, today we'll build a Python and Flask webapp for finding and booking vacation properties — tentatively called Airtng.

Here's how it'll work:

A host creates a vacation property listing
A guest requests a reservation for a property
The host receives an SMS notifying them of the reservation request. The host can either Accept or Reject the reservation
The guest is notified whether a request was rejected or accepted

Learn how Airbnb used Twilio SMS to streamline the rental experience for 60M+ travelers around the world.

Workflow Building Blocks

We'll be using the Twilio REST API to send our users messages at important junctures. Here's a bit more on our API:

Sending Messages with Twilio API

Load the application configuration

airtng_flask/__init__.py

1import os
2from airtng_flask.config import config_env_files
3from flask import Flask
4
5from flask_bcrypt import Bcrypt
6from flask_sqlalchemy import SQLAlchemy
7from flask_login import LoginManager
8
9db = SQLAlchemy()
10bcrypt = Bcrypt()
11login_manager = LoginManager()
12
13
14def create_app(config_name='development', p_db=db, p_bcrypt=bcrypt, p_login_manager=login_manager):
15    new_app = Flask(__name__)
16    config_app(config_name, new_app)
17    new_app.config['SQLALCHEMY_TRACK_MODIFICATIONS'] = False
18
19    p_db.init_app(new_app)
20    p_bcrypt.init_app(new_app)
21    p_login_manager.init_app(new_app)
22    p_login_manager.login_view = 'register'
23    return new_app
24
25
26def config_app(config_name, new_app):
27    new_app.config.from_object(config_env_files[config_name])
28
29
30app = create_app()
31
32import airtng_flask.views

Let's get started! Click the below button to begin.

User and Session Management

For this workflow to work, we need to have Users created in our application, and allow them to log into Airtng.

Our User model stores a user's basic information including their phone number. We'll use that to send them SMS notifications later.

The Airtng User model

airtng_flask/models/user.py

1from airtng_flask.models import app_db
2from airtng_flask.models import bcrypt
3
4db = app_db()
5bcrypt = bcrypt()
6
7
8class User(db.Model):
9    __tablename__ = "users"
10
11    id = db.Column(db.Integer, primary_key=True)
12    name = db.Column(db.String, nullable=False)
13    email = db.Column(db.String, nullable=False)
14    password = db.Column(db.String, nullable=False)
15    phone_number = db.Column(db.String, nullable=False)
16
17    reservations = db.relationship("Reservation", back_populates="guest")
18    vacation_properties = db.relationship("VacationProperty", back_populates="host")
19
20    def __init__(self, name, email, password, phone_number):
21        self.name = name
22        self.email = email
23        self.password = bcrypt.generate_password_hash(password)
24        self.phone_number = phone_number
25
26    def is_authenticated(self):
27        return True
28
29    def is_active(self):
30        return True
31
32    def is_anonymous(self):
33        return False
34
35    def get_id(self):
36        try:
37            return unicode(self.id)
38        except NameError:
39            return str(self.id)
40
41    # Python 3
42
43    def __unicode__(self):
44        return self.name
45
46    def __repr__(self):
47        return '<User %r>' % (self.name)

Next, let's look at how we define the VacationProperty model.

The VacationProperty Model

In order to build a vacation rentals company we need a way to create the property listings.

The VacationProperty model belongs to the User who created it (we'll call this user the host moving forward) and contains only two properties: a description and an image_url.

We also include a couple database relationship fields to help us link vacation properties to their hosts as well as to any reservations our users make.

VacationProperty model

airtng_flask/models/vacation_property.py

1from airtng_flask.models import app_db
2
3db = app_db()
4
5
6class VacationProperty(db.Model):
7    __tablename__ = "vacation_properties"
8
9    id = db.Column(db.Integer, primary_key=True)
10    description = db.Column(db.String, nullable=False)
11    image_url = db.Column(db.String, nullable=False)
12
13    host_id = db.Column(db.Integer, db.ForeignKey('users.id'))
14    host = db.relationship("User", back_populates="vacation_properties")
15    reservations = db.relationship("Reservation", back_populates="vacation_property")
16
17    def __init__(self, description, image_url, host):
18        self.description = description
19        self.image_url = image_url
20        self.host = host
21
22    def __repr__(self):
23        return '<VacationProperty %r %r>' % self.id, self.description

Next we'll take a look at how to model a reservation.

The Reservation Model

The Reservation model is at the center of the workflow for this application. It is responsible for keeping track of:

The guest who performed the reservation
The vacation_property the guest is requesting (and associated host)
The status of the reservation: pending, confirmed, or rejected

The Reservation model

airtng_flask/models/reservation.py

1from airtng_flask.models import app_db, auth_token, account_sid, phone_number
2from flask import render_template
3from twilio.rest import Client
4
5db = app_db()
6
7
8class Reservation(db.Model):
9    __tablename__ = "reservations"
10
11    id = db.Column(db.Integer, primary_key=True)
12    message = db.Column(db.String, nullable=False)
13    status = db.Column(db.Enum('pending', 'confirmed', 'rejected', name='reservation_status_enum'), default='pending')
14
15    guest_id = db.Column(db.Integer, db.ForeignKey('users.id'))
16    vacation_property_id = db.Column(db.Integer, db.ForeignKey('vacation_properties.id'))
17    guest = db.relationship("User", back_populates="reservations")
18    vacation_property = db.relationship("VacationProperty", back_populates="reservations")
19
20    def __init__(self, message, vacation_property, guest):
21        self.message = message
22        self.guest = guest
23        self.vacation_property = vacation_property
24        self.status = 'pending'
25
26    def confirm(self):
27        self.status = 'confirmed'
28
29    def reject(self):
30        self.status = 'rejected'
31
32    def __repr__(self):
33        return '<VacationProperty %r %r>' % self.id, self.name
34
35    def notify_host(self):
36        self._send_message(self.vacation_property.host.phone_number,
37                           render_template('messages/sms_host.txt',
38                                           name=self.guest.name,
39                                           description=self.vacation_property.description,
40                                           message=self.message))
41
42    def notify_guest(self):
43        self._send_message(self.guest.phone_number,
44                           render_template('messages/sms_guest.txt',
45                                           description=self.vacation_property.description,
46                                           status=self.status))
47
48    def _get_twilio_client(self):
49        return Client(account_sid(), auth_token())
50
51    def _send_message(self, to, message):
52        self._get_twilio_client().messages.create(
53                to=to,
54                from_=phone_number(),
55                body=message)

Now that we have our models, let's see how a user would create a reservation.

Creating a Reservation

The reservation creation form holds only one field, the message that will be sent to the host user when reserving one of her properties.

The rest of the information necessary to create a reservation is taken from the user that is logged into the system and the relationship between a property and its owning host.

A reservation is created with a default status pending, so when the host replies with an accept or reject response, the system knows which reservation to update.

Routes for the Airtng workflow

airtng_flask/views.py

1from airtng_flask import db, bcrypt, app, login_manager
2from flask import session, g, request, flash, Blueprint
3from flask_login import login_user, logout_user, current_user, login_required
4from twilio.twiml.voice_response import VoiceResponse
5
6from airtng_flask.forms import RegisterForm, LoginForm, VacationPropertyForm, ReservationForm, \
7    ReservationConfirmationForm
8from airtng_flask.view_helpers import twiml, view, redirect_to, view_with_params
9from airtng_flask.models import init_models_module
10
11init_models_module(db, bcrypt, app)
12
13from airtng_flask.models.user import User
14from airtng_flask.models.vacation_property import VacationProperty
15from airtng_flask.models.reservation import Reservation
16
17
18@app.route('/', methods=["GET", "POST"])
19@app.route('/register', methods=["GET", "POST"])
20def register():
21    form = RegisterForm()
22    if request.method == 'POST':
23        if form.validate_on_submit():
24
25            if User.query.filter(User.email == form.email.data).count() > 0:
26                form.email.errors.append("Email address already in use.")
27                return view('register', form)
28
29            user = User(
30                    name=form.name.data,
31                    email=form.email.data,
32                    password=form.password.data,
33                    phone_number="+{0}{1}".format(form.country_code.data, form.phone_number.data)
34            )
35            db.session.add(user)
36            db.session.commit()
37            login_user(user, remember=True)
38
39            return redirect_to('home')
40        else:
41            return view('register', form)
42
43    return view('register', form)
44
45
46@app.route('/login', methods=["GET", "POST"])
47def login():
48    form = LoginForm()
49    if request.method == 'POST':
50        if form.validate_on_submit():
51            candidate_user = User.query.filter(User.email == form.email.data).first()
52
53            if candidate_user is None or not bcrypt.check_password_hash(candidate_user.password,
54                                                                        form.password.data):
55                form.password.errors.append("Invalid credentials.")
56                return view('login', form)
57
58            login_user(candidate_user, remember=True)
59            return redirect_to('home')
60    return view('login', form)
61
62
63@app.route('/logout', methods=["POST"])
64@login_required
65def logout():
66    logout_user()
67    return redirect_to('home')
68
69
70@app.route('/home', methods=["GET"])
71@login_required
72def home():
73    return view('home')
74
75
76@app.route('/properties', methods=["GET"])
77@login_required
78def properties():
79    vacation_properties = VacationProperty.query.all()
80    return view_with_params('properties', vacation_properties=vacation_properties)
81
82
83@app.route('/properties/new', methods=["GET", "POST"])
84@login_required
85def new_property():
86    form = VacationPropertyForm()
87    if request.method == 'POST':
88        if form.validate_on_submit():
89            host = User.query.get(current_user.get_id())
90
91            property = VacationProperty(form.description.data, form.image_url.data, host)
92            db.session.add(property)
93            db.session.commit()
94            return redirect_to('properties')
95
96    return view('property_new', form)
97
98
99@app.route('/reservations/', methods=["POST"], defaults={'property_id': None})
100@app.route('/reservations/<property_id>', methods=["GET", "POST"])
101@login_required
102def new_reservation(property_id):
103    vacation_property = None
104    form = ReservationForm()
105    form.property_id.data = property_id
106
107    if request.method == 'POST':
108        if form.validate_on_submit():
109            guest = User.query.get(current_user.get_id())
110
111            vacation_property = VacationProperty.query.get(form.property_id.data)
112            reservation = Reservation(form.message.data, vacation_property, guest)
113            db.session.add(reservation)
114            db.session.commit()
115
116            reservation.notify_host()
117
118            return redirect_to('properties')
119
120    if property_id is not None:
121        vacation_property = VacationProperty.query.get(property_id)
122
123    return view_with_params('reservation', vacation_property=vacation_property, form=form)
124
125
126@app.route('/confirm', methods=["POST"])
127def confirm_reservation():
128    form = ReservationConfirmationForm()
129    sms_response_text = "Sorry, it looks like you don't have any reservations to respond to."
130
131    user = User.query.filter(User.phone_number == form.From.data).first()
132    reservation = Reservation \
133        .query \
134        .filter(Reservation.status == 'pending'
135                and Reservation.vacation_property.host.id == user.id) \
136        .first()
137
138    if reservation is not None:
139
140        if 'yes' in form.Body.data or 'accept' in form.Body.data:
141            reservation.confirm()
142        else:
143            reservation.reject()
144
145        db.session.commit()
146
147        sms_response_text = "You have successfully {0} the reservation".format(reservation.status)
148        reservation.notify_guest()
149
150    return twiml(_respond_message(sms_response_text))
151
152
153# controller utils
154@app.before_request
155def before_request():
156    g.user = current_user
157    uri_pattern = request.url_rule
158    if current_user.is_authenticated and (
159                        uri_pattern == '/' or uri_pattern == '/login' or uri_pattern == '/register'):
160        redirect_to('home')
161
162
163@login_manager.user_loader
164def load_user(id):
165    try:
166        return User.query.get(id)
167    except:
168        return None
169
170
171def _respond_message(message):
172    response = VoiceResponse()
173    response.message(message)
174    return response

Now that we have seen how we will initiate a reservation, let's look at how to notify the host.

Notify the Host via SMS

When a reservation is created for a property, we want to notify the host of the reservation request.

We use Twilio's Rest API to send a SMS message to the host, using a Twilio phone number.

Now we just have to wait for the host to send an SMS response accepting or rejecting the reservation. At that point we can notify the user and host and update the reservation information accordingly.

Notify the user and the host

airtng_flask/models/reservation.py

1from airtng_flask.models import app_db, auth_token, account_sid, phone_number
2from flask import render_template
3from twilio.rest import Client
4
5db = app_db()
6
7
8class Reservation(db.Model):
9    __tablename__ = "reservations"
10
11    id = db.Column(db.Integer, primary_key=True)
12    message = db.Column(db.String, nullable=False)
13    status = db.Column(db.Enum('pending', 'confirmed', 'rejected', name='reservation_status_enum'), default='pending')
14
15    guest_id = db.Column(db.Integer, db.ForeignKey('users.id'))
16    vacation_property_id = db.Column(db.Integer, db.ForeignKey('vacation_properties.id'))
17    guest = db.relationship("User", back_populates="reservations")
18    vacation_property = db.relationship("VacationProperty", back_populates="reservations")
19
20    def __init__(self, message, vacation_property, guest):
21        self.message = message
22        self.guest = guest
23        self.vacation_property = vacation_property
24        self.status = 'pending'
25
26    def confirm(self):
27        self.status = 'confirmed'
28
29    def reject(self):
30        self.status = 'rejected'
31
32    def __repr__(self):
33        return '<VacationProperty %r %r>' % self.id, self.name
34
35    def notify_host(self):
36        self._send_message(self.vacation_property.host.phone_number,
37                           render_template('messages/sms_host.txt',
38                                           name=self.guest.name,
39                                           description=self.vacation_property.description,
40                                           message=self.message))
41
42    def notify_guest(self):
43        self._send_message(self.guest.phone_number,
44                           render_template('messages/sms_guest.txt',
45                                           description=self.vacation_property.description,
46                                           status=self.status))
47
48    def _get_twilio_client(self):
49        return Client(account_sid(), auth_token())
50
51    def _send_message(self, to, message):
52        self._get_twilio_client().messages.create(
53                to=to,
54                from_=phone_number(),
55                body=message)

Next, let's see how to handle incoming messages from Twilio webhooks.

Handle Incoming Twilio Requests

This method handles the Twilio request triggered by the host's SMS and does three things:

Checks for a pending reservation from a user
Updates the status of the reservation
Responds to the host and sends a notification to the user

Setting Up Incoming Twilio Requests

In the Twilio console, you should change the 'A Message Comes In' webhook to call your application's endpoint in the route /confirm:

One way to expose your machine to the world during development is using ngrok. Your URL for the SMS web hook on your phone number should look something like this:

1http://<subdomain>.ngrok.io/confirm
2

An incoming request from Twilio comes with some helpful parameters. These include the From phone number and the message Body.

We'll use the From parameter to look up the host and check if they have any pending reservations. If they do, we'll use the message body to check for the message 'accepted' or 'rejected'. Finally, we update the reservation status and use the SmsNotifier abstraction to send an SMS to the guest telling them the host accepted or rejected their reservation request.

TwiML Response

In our response to Twilio, we'll use Twilio's TwiML Markup Language to command Twilio to send an SMS notification message to the host.

Confirm or reject a pending reservation request

airtng_flask/views.py

1from airtng_flask import db, bcrypt, app, login_manager
2from flask import session, g, request, flash, Blueprint
3from flask_login import login_user, logout_user, current_user, login_required
4from twilio.twiml.voice_response import VoiceResponse
5
6from airtng_flask.forms import RegisterForm, LoginForm, VacationPropertyForm, ReservationForm, \
7    ReservationConfirmationForm
8from airtng_flask.view_helpers import twiml, view, redirect_to, view_with_params
9from airtng_flask.models import init_models_module
10
11init_models_module(db, bcrypt, app)
12
13from airtng_flask.models.user import User
14from airtng_flask.models.vacation_property import VacationProperty
15from airtng_flask.models.reservation import Reservation
16
17
18@app.route('/', methods=["GET", "POST"])
19@app.route('/register', methods=["GET", "POST"])
20def register():
21    form = RegisterForm()
22    if request.method == 'POST':
23        if form.validate_on_submit():
24
25            if User.query.filter(User.email == form.email.data).count() > 0:
26                form.email.errors.append("Email address already in use.")
27                return view('register', form)
28
29            user = User(
30                    name=form.name.data,
31                    email=form.email.data,
32                    password=form.password.data,
33                    phone_number="+{0}{1}".format(form.country_code.data, form.phone_number.data)
34            )
35            db.session.add(user)
36            db.session.commit()
37            login_user(user, remember=True)
38
39            return redirect_to('home')
40        else:
41            return view('register', form)
42
43    return view('register', form)
44
45
46@app.route('/login', methods=["GET", "POST"])
47def login():
48    form = LoginForm()
49    if request.method == 'POST':
50        if form.validate_on_submit():
51            candidate_user = User.query.filter(User.email == form.email.data).first()
52
53            if candidate_user is None or not bcrypt.check_password_hash(candidate_user.password,
54                                                                        form.password.data):
55                form.password.errors.append("Invalid credentials.")
56                return view('login', form)
57
58            login_user(candidate_user, remember=True)
59            return redirect_to('home')
60    return view('login', form)
61
62
63@app.route('/logout', methods=["POST"])
64@login_required
65def logout():
66    logout_user()
67    return redirect_to('home')
68
69
70@app.route('/home', methods=["GET"])
71@login_required
72def home():
73    return view('home')
74
75
76@app.route('/properties', methods=["GET"])
77@login_required
78def properties():
79    vacation_properties = VacationProperty.query.all()
80    return view_with_params('properties', vacation_properties=vacation_properties)
81
82
83@app.route('/properties/new', methods=["GET", "POST"])
84@login_required
85def new_property():
86    form = VacationPropertyForm()
87    if request.method == 'POST':
88        if form.validate_on_submit():
89            host = User.query.get(current_user.get_id())
90
91            property = VacationProperty(form.description.data, form.image_url.data, host)
92            db.session.add(property)
93            db.session.commit()
94            return redirect_to('properties')
95
96    return view('property_new', form)
97
98
99@app.route('/reservations/', methods=["POST"], defaults={'property_id': None})
100@app.route('/reservations/<property_id>', methods=["GET", "POST"])
101@login_required
102def new_reservation(property_id):
103    vacation_property = None
104    form = ReservationForm()
105    form.property_id.data = property_id
106
107    if request.method == 'POST':
108        if form.validate_on_submit():
109            guest = User.query.get(current_user.get_id())
110
111            vacation_property = VacationProperty.query.get(form.property_id.data)
112            reservation = Reservation(form.message.data, vacation_property, guest)
113            db.session.add(reservation)
114            db.session.commit()
115
116            reservation.notify_host()
117
118            return redirect_to('properties')
119
120    if property_id is not None:
121        vacation_property = VacationProperty.query.get(property_id)
122
123    return view_with_params('reservation', vacation_property=vacation_property, form=form)
124
125
126@app.route('/confirm', methods=["POST"])
127def confirm_reservation():
128    form = ReservationConfirmationForm()
129    sms_response_text = "Sorry, it looks like you don't have any reservations to respond to."
130
131    user = User.query.filter(User.phone_number == form.From.data).first()
132    reservation = Reservation \
133        .query \
134        .filter(Reservation.status == 'pending'
135                and Reservation.vacation_property.host.id == user.id) \
136        .first()
137
138    if reservation is not None:
139
140        if 'yes' in form.Body.data or 'accept' in form.Body.data:
141            reservation.confirm()
142        else:
143            reservation.reject()
144
145        db.session.commit()
146
147        sms_response_text = "You have successfully {0} the reservation".format(reservation.status)
148        reservation.notify_guest()
149
150    return twiml(_respond_message(sms_response_text))
151
152
153# controller utils
154@app.before_request
155def before_request():
156    g.user = current_user
157    uri_pattern = request.url_rule
158    if current_user.is_authenticated and (
159                        uri_pattern == '/' or uri_pattern == '/login' or uri_pattern == '/register'):
160        redirect_to('home')
161
162
163@login_manager.user_loader
164def load_user(id):
165    try:
166        return User.query.get(id)
167    except:
168        return None
169
170
171def _respond_message(message):
172    response = VoiceResponse()
173    response.message(message)
174    return response

Congratulations!

You've just learned how to automate your workflow with Twilio Programmable SMS. In the next pane, we'll look at some other features you can add.

Where to Next?

To improve upon this you could add anonymous communications so that the host and guest could communicate through a shared Twilio phone number: Call Masking with Python and Flask.

You might also enjoy these other tutorials:

IVR Phone Tree

Create a seamless customer service experience by building an IVR (Interactive Voice Response) Phone Tree for your company.

Click To Call

Convert web traffic into phone calls with the click of a button.
